LigoDLB 5-90n

Highlights:

۵٫۱۵۰ – ۵٫۸۵۰ GHz (FCC 5.150 – 5.250 and 5.725 – 5.850 GHz)
۸۰,۰۰۰ PPS
۱۷۰ Mbps capacity
High output power 29 dBm radio
Integrated 18 dBi dual-polarized 90 degree sector antenna
Powerful OS
Smart polling data transmission protocol (iPoll 3)
Meets IP – ۶۶ certification
Integrated surge protection
Responsive HTML 5 based GUI
Pole mounting

حداکثر فاصله در حالت PTP

Not Applicable

حداکثر فاصله در حالت PTMP

7km80%
80%
[us_single_image image=”6453″ size=”full” align=”center”]

ارتباطات روستایی

[us_single_image image=”6452″ size=”full” align=”center”]

نظارت تصویری

[us_single_image image=”6451″ size=”full” align=”center”]

دسترسی اینترنت

[us_single_image image=”6033″ size=”full” align=”center”]

Small Form Factor

[us_single_image image=”6034″ size=”full” align=”center”]

Innovative Mounting Bracket

Pole Mounting

Tilt the device in any of four directions—up, down, left, or right—with the DLB Pole Mount, thus ensuring ideal precision tilting and optimum link adaptability.

[us_single_image image=”6036″ size=”full” align=”center”]

Hardware Built to Last

A powerful new generation CPU ensures better performance delivering higher—up to 170Mbps—throughput and almost 2× greater packet per second rate (80,000). The addition of RAM improves performance, allowing multiple users to be connected to a single base-station, and the larger flash capacity stores a 2nd failover firmware image.

Hardware Built to Last

A powerful new generation CPU ensures better performance delivering higher—up to 170Mbps—throughput and almost 2× greater packet per second rate (80,000). The addition of RAM improves performance, allowing multiple users to be connected to a single base-station, and the larger flash capacity stores a 2nd failover firmware image.
[us_single_image image=”6007″ size=”full” align=”center”]

LigoWave OS

LigoWave OS contains all of the essential features for establishing fast, strong, and reliable PTMP networks. The LigoWave OS includes IPv6 Bridge & Router Support, SSDP & Bonjour Device Discovery Options, Flexible Traffic Shaping, DHCP Option 82, and more. The user interface is built on HTML5 with responsive design.

[us_single_image image=”6420″ size=”full” align=”center”]

iPoll 3: Enhanced Performance Protocol

LigoWave’s iPoll™ PTMP (Point-to-Multi-Point) proprietary protocol is an innovative solution, eliminating transmission congestion and close-cluster interference created in wireless PTMP installations.

[us_single_image image=”6421″ size=”full” align=”center”]

LigoDLB 5-90n Datasheet

LigoWave products overview

DLB Installation guide

iPoll technical paper

Network upgrade with LigoDLB ac

iPoll 3 case study
